Optrel Crystal 2.0 Auto Darkening Helmet

Optrel Crystal 2.0 – Best Auto Darkening Helmet in Malaysia

Category:
Add to Enquiry
Share with your friends:

Technical Data

Designed to only protect all welders’ eyes from any dangerous radiation, the Optrel Crystal 2.0 auto-darkening welding helmet is designed to shield you from harmful ultraviolet and infrared radiation, as well as visible light resulting from certain arc ad gas welding processes. This auto darkening helmet can be used for various electro welding, plasma welding, cutting, and other welding processes in Malaysia.

Technical Data

Shade levels

inactive: shade level 2.0

active, manual: shade level 4-12



Autopilot: Automatic protection level regulation across a range from 4-12 with individual calibration option of ± 2



Power supply: Solar cells, 2 lithium batteries (CR2032)



Sensors: Three Sensors



Sensitivity: Infinitely adjustable, now with “super high” sensitivity



Switching time

bright to dark: 0.100 ms at room temperature at 55°C
0.070 ms at 55°C
dark to bright: 0.1 s to 2.0 s (with dimming function)



EN379 classification

Optical class: 1
Scattered light: 1
Homogeneity: 1
Angular dependence: 2



Shape stability

Welding mask: up to 220 °C / 428 °F
Front cover lens: up to 137 °C / 279 °F



Eye protection Ultraviolet / Infrared Protection

maximum protection at any shade level



Operating temperature:

-10°C to + 70°C / 14°F to 158°F



Storage temperature

-20°C to + 80°C / -4°F to 176°F



Weight

460 g / 18,7 oz



Scope of delivery

Welding helmet, manual



Warranty

2 years
1 year warranty extension (except batteries) for online product registration within the first 6 months.



Features

True colour vision –
directly when welding.

For the first time in the history of welding you as a welder see the joining process as it actually takes place. How the weld pool melts, how the weld seam is created. You can see how the filler material is immersed in the welding pool and gain complete control over your work.

CLT offers you brilliant vision, like through a window pane. Crystal clear. And thanks to optrel Autopilot always with the right protection level.

True color means not the same as true color

As far as always the distinction can be seen upon taking a closer look. With the crystal lens technology you will recognize the difference immediately when putting it on.

The color perception in light state is almost like looking through clear window glass and in dark mode you enjoy a detailled and high-contrast view of the welding pool with a never-seen-before clearness.





Crystal Lens Technology 2.0

Autopilot
Shade Level 4-12

Hard Hat Adapter

Sensitivity Adjustment

Twilight Function

Comfort Headband

Lightweight

Patented Excenter

Grind Mode

Outside Adjustment

True Color View

Warranty Extension 2+1 Years

Product

https://industrial.optrel.com/fileadmin/optrel/redaktion/pdf/en/productflyers/crystal-flyer-8S-en.pdf

Fields of Application

  • Elektrode Welding (Stick Welding, SMAW)
  • MIG/MAG (GMAW)
  • GMAW High melting rate process
  • Flux Cored Wire Welding
  • TIG Welding (GTAW)
  • Plasma Arc Welding
  • Micro Plasma Arc Welding
  • Plasma Cutting
  • Gas Welding
  • Grind Mode
